Pure sine wave
The built-in electronic unit with microprocessor control monitors the operation of the generator and provides a stable output voltage of 230V 50Hz sinusoidal form, which is suitable for the reliable operation of sensitive electronics.
| Voltage, V |
230 |
| Max power, kW |
3.1 |
| Nominal power, kW |
2.8 |
| Frequency, Hz |
50 |
| Current (max), A |
13.5 |
| Outlets |
1 x Schuko 230 V |
| Engine start |
Manual |
| Fuel tank volume, l |
4 |
| Avg. working time (power 50%), h*** |
2.7 |
| LED display |
Voltage, frequency, working hours |
| Noise level Lpa (7m)/Lwa, dB |
63/88 |
| Power output DC, V/А |
12V/8.3A |
| USB-Outputs |
5V/1A, 5V/2.1A |
| Engine model |
KS 160i |
| Engine cylinder volume, cm3 |
145 |
| Engine type |
Gasoline powered one-cylinder, four-stroke air-cooled |
| Engine power, hp |
5 |
| Possibility of parallel connection |
+ |
| Crank case volume, l |
0.45 |
| Alternator winding |
Copper |
| Protection class |
IP23M |
| Net dimensions (LxWxH), mm |
480x290x430 |
| Gross dimensions (LxWxH), mm |
510x320x475 |
| Net weight, kg |
21.5 |
| Gross weight, kg |
23.9 |
| SKU |
KS 3100i S |
| Barcode |
4260405365555 |
*** Fuel consumption depends on many factors, such as load, fuel quality, season, altitude, technical condition of the generator.
